Model |
BY214x8/16(1)H |
BY214x8/16(2)H |
BY214x8/16(3)H |
Total pressure |
160ton |
160ton |
160ton |
Feeding direction |
Transversal |
Transversal |
Transversal |
Dimension of hot platen |
2500x1300x42mm |
2500x1300x42mm |
2500x1300x42mm |
Number of layers |
1 |
2 |
3 |
Number of platens |
2 |
3 |
4 |
Opening |
200mm |
200mm |
300mm |
Diameter & stroke of Oil cylinder |
Ф100mmx200mm |
Ф100mmx200mm |
Ф100mmx300mm |
Number of cylinders |
8 |
8 |
8 |
Heating medium |
Steam or thermal oil |
Steam or thermal oil |
Steam or thermal oil |
Frame structure |
Welded |
Welded |
Welded |
Working pressure of high pump |
25.2Mpa |
25.2Mpa |
25.5Mpa |
Total power |
7Kw |
7Kw |
7Kw |
Thermal Oil Furnace |
55.5Kw |
55.5Kw |
55.5Kw |
Net Weight (Approx) |
7000Kg |
8000Kg |
9000Kg |
Max working temperature |
120℃ |
120℃ |
120℃ |
