Model |
BY214x9/16(1)H |
BY214x9/16(2)H |
BY214x9/16(3)H |
Total pressure |
160ton |
160ton |
160ton |
Dimension of hot platen |
3000x1300x42mm |
3000x1300x42mm |
3000x1300x42mm |
Number of layers |
1 |
2 |
3 |
Opening |
200mm |
300mm |
300mm |
Diameter & stroke of Oil cylinder |
Ф100mm* 200mm |
Ф100mm* 300mm |
Ф100mm* 300mm |
Number of cylinders |
8 |
8 |
8 |
Low pressure pump flux |
63L/min |
63L/min |
63L/min |
High pressure pump flux |
2.5L/min |
2.5L/min |
2.5L/min |
Heating medium |
Steam or thermal oil |
Steam or thermal oil |
Steam or thermal oil |
Working pressure of high pump |
25Mpa |
25Mpa |
25Mpa |
Total power |
5.5Kw |
5.5Kw |
5.5Kw |
Heating system power |
37.5Kw |
37.5Kw |
37.5Kw |
Overall dimension (Approx) |
4700x1700x2000 |
4700x1700x2100 |
4700x1700x2100 |
Net Weight (Approx) |
8300Kg |
9600Kg |
10600Kg |
